Chlory hypochlorous acid generator adopts advanced PEM electrolysis technology to produce stable, pure hypochlorous acid anolyte with adjustable concentrations of 100ppm, 200ppm and 500ppm. It is widely used in medical disinfection, food processing, animal husbandry, public space and water treatment.
Working Principle
The system electrolyzes dilute salt water through a PEM electrolytic cell. Under the separation of cation exchange membrane, the anode generates high-purity hypochlorous acid solution, while the cathode produces alkaline water. Only salt, water and electricity are needed for on-site disinfectant production, with low cost and stable performance.
Technical Specifications
| Item | Parameter |
|---|---|
| HOCL Concentration | 100ppm, 200ppm, 500ppm adjustable |
| pH Value | 4.5 – 6.5 |
| ORP | 1000 – 1200mV |
| Power Supply | AC220V/380V 50/60Hz |
| Certification | CE, ISO |
Model List
| Model | BH-H | BH-M | BH-E | BH-T | BH-K |
| Feature |
Household Pet Clinic |
Common type |
Medical grade Strong HOCL Three Outputs Disinfectants |
Top Grade For Medicine |
Surface disinfection Water disinfection |
| Input |
Tap Water Kitchen SALT ELECTRICITY |
RO WATER 99.5% NACI ELECTRICITY |
RO WATER Normal Salt ELECTRICITY |
Tap Water *SALT* ELECTRICITY |
CLEAN WATER Special Salt ELECTRICITY |
| Output |
HOCL Alkaline 800ml/time |
HOCL Alkaline NAOH 50L-2000L/H |
HOCL Sodium Hypo Alkaline NaOH 50L-2000L/H |
Only Pure HOCL Water 50L-2000L/H |
Only HOCL water 50L-2000L/H |
| HOCL Concentration | 20-100ppm | 20-500ppm | 20-2000ppm | 100-300ppm | 15000ppm |
| pH adjustable | 2-6.5 | 4.5-6.5 | 4.5-6.5 | ||
| >850 | >800 | >900 | >1000 | >900 | |
| Shelflife | 6 months | 12 months | 12 months | 12 months | 15 months |
| PLC Auto Control | √ | √ | √ | √ | √ |
Grade and application comparison table
| Category | Pharmaceutical Grade | Medical Grade | Common Grade |
| Concentration (Max) | 0-200 ppm, 0-500 ppm, 0-1500 ppm | 0-2000 ppm | 0-500 ppm |
| Raw Material | Self-Made | Salt | Salt |
| Applications | Wound, skin, nose, foot, oral, burns, scalds, women's cleaning, epidemic prevention and control, disinfection | Medical equipment disinfection, surgery, hospital environment, cosmetics, face cleaning | Poultry farm, planting, food/seafood processing, pet disinfection, room cleaning, surface disinfection |
| Product |
|
|
|
Machine Datasheet:
|
Dimensions |
1000X750X1350mm |
|
Land Size (Area) |
3000X3000X2500mm |
|
HOCL Concentration |
50-500ppm 500-1500ppm 2000-15000ppm |
|
Production Capacity |
50L/H -1000L/H |
|
Natural Acidic (Range) |
pH4.5 ~7 |
|
Total Power Consumption |
1KW-3KW |
|
Electricity Supply |
AC 220V /50 -60 Hz AC 380V /50 -60 Hz |
|
Power Distribution Req. |
≥ 3000W |
Main features for HCIO acid water Generator,
1-Manual Full Automatic Working, only 1 person required.
2- LED/LCE touch Screen operation, remote control by app on iPHONE/Android
3- Real time online display HOCI Concentration(ppm), pH,Electrolytic current,Temperature
4- Warning and Alarm when problem occured
5- Continuous produing the disinfectant up to 24hours/day
Applications
- Medical & hospital: equipment, environment, wound disinfection
- Food & beverage: processing, cleaning, fresh-keeping
- Livestock & poultry breeding: farm disinfection, air spray
- Public places: hotel, school, office, vehicle disinfection
- Water treatment: drinking water, circulating water disinfection
- Daily & pet: household cleaning, pet care
Why Choose Chlory HOCL Generator?
- Stable PEM core technology, long service life
- On-site production, reduce storage and transportation cost
- Intelligent control, 24-hour unattended operation
- Multiple safety protections and alarm system
- Customizable capacity and concentration for different demands
Frequently Asked Questions
Q: What materials are needed to run the machine?
A: Only food grade or industrial salt, clean water and electricity are required.
Q: Can the concentration be adjusted freely?
A: Yes, the machine supports stable output of 100ppm, 200ppm and 500ppm hypochlorous acid.
Q: Is it suitable for food and medical use?
A: Yes, our HOCL generator meets food safety and medical disinfection standards.
